HAND TOOLS
Made in
19/3
LEVERS FOR LAYING ROLLS AND RUBBER-SHOE UNDER RAILS
USE : Free internaI rail stress in continuous length of rails.
ƒ ƒ Carrying of under-rails Steel Rolls to free internal stress in continuous Length of
rails.
ƒ ƒ Replacing of the Rubber-Shoe under rail
(In France, it is prohibited to carry out such work between the 15th of June to the
15th of September )
ADVANTAGES : Simple and Tough Tools..
SINGLE LEVER - Ref. 105-B
ƒ ƒ Ø 30 mm x Length 1.10 m Hard Steel Lever
ƒ ƒ Weight 7 Kg
ƒ ƒ Paint black varnish
The 105-B Lever takes off from the top of Sleeper,
and by action on the Arm, the rail is raised very easily.
DEMULTIPLICATING LEVER - Ref. LRD
ƒ ƒ Vertical Lifting Stroke 50 mm
ƒ ƒ Lifting Capacity 1 ton
ƒ ƒ Lever, Length 1.20 m
ƒ ƒ Net Weight 14 Kg
ƒ ƒ Paint yellow varnish
The LRD Lever takes off on each side of the rail on Sleeper
and by action on the Arm, the rail is raised very easily.
UNDER RAIL PLAQUE
ƒ ƒ Ref. PL-1 (0.65 Kg) With 1 rail and handle.
ƒ ƒ Ref. PL-2 (3 Kg), With 2 steel rails and handle.
LIGHTWEIGHT Gantry Crane Model «Trestle» - Ref. 560/6
ƒ ƒ Lifting Capacity 1 Ton
ƒ ƒ Hoist with Security Crank Handle
ƒ ƒ Net Weight 23 Kg
ƒ ƒ Made in all aluminium, operated by 2 Agents (Tech. Spec. No 34/3)
ROLLS to free internal stress in continuous Length of rails
(Hard Steel Rolls positinned under-rails)
ƒ ƒ Ø 25 mm - Ref. R-25
ƒ ƒ Ø 20 mm - Ref. R-20
ƒ ƒ Ø 14 mm - Ref. R-14
RUBBER HAMMERS - Ref. 305 to free internal stress in continuous
Length of rails and other works with Handle 1.10 m - Weight 3 Kg (see Tech. Spec No. 22/3)
See Tech. Spec. No. 38/3
