MG MOVABLE LIGHTING SETS
USE : For night works, in tunnel, or for assistance.
AVANTAGES : Self-equipment, compact and silent. Removed everywhere by a
single man. Improved safety : there is not cable on ground.
GENERATOR : Petrol engine 4-stroke HONDA
Alternator 230 V - 50 Hz
with battery-stoker 12 V
Sound intensity : 83 dB(A)
LIGHTS : Telescopic and dismountable in 2 parts
Adjustable elevation from 1.4 m. to 2.7 m.
Halogen lights or fluorescent
Tight and orientable lights (Protection class IP-55)
with protection anti-impact.
The set is equipped on a frame in steel protector tubes,
with 2 folding hands for transport, and 2 inflating rubber
wheels Ø 250 mm (Wheels centers : 35 cm.),
allowing the circulation on narrow side path.
GENERATING
SET POWER
(W)
LIGHTS
NETWEIGHT of
Complete Lighting
Set KG
MODEL
600 1 Halogen Light 500 W 30 MG-1
1000
2 Halogen Lights
500 W each 35 MG-2
600
1 Fluo Light 72 W
with polycarbonate diffuser 32 MG-3
600
2 Fluo Light 72 W
with polycarbonate diffuser 35 MG-4
Dimensions of the folder Set (overall length) :
ƒ ƒ Length : 62 cm
ƒ ƒ Width : 52 cm
ƒ ƒ Height : 58 cm
