LIGHTWEIGHT MOVABLE SCAFFOLDING
This Scaffold may be manually pushed along the Track (Rail and Underground / Metro) and it features
a Security «Dead Man’s» Control Braking Device acting on Wheels simultaneously.
Technical characteristics (Assembly and dismantling : 2 Operating Agents in 20 min.)
ƒ ƒ 1 Lorry with Ø 250 mmWheels (all aluminium)
ƒ ƒ 1 Identical Lorry with « Dead-Man’s » Control Device acting on 2 Wheels simultaneously.
ƒ ƒ 1 Complete Set of ALUMINIUM Scaffold with Movable Floors, Plinths and Handrails.
ƒ ƒ Dimensions :
ƒ ƒ
: 2 Lateral Extensions, Width 0.60 m / 1 m. - (Photo 3)
References :
USE : Work in Tunnel and Underground.
ADVANTAGES : Ultra-Lightweight Equipment, it is easy to use and transport and very safe to operate.
APAVE / VERITAS Inspection Certificate on request.
OPTIONS
ƒ ƒ Safety Rail Tong with Rollers (Photo 2) for Lateral Extension - Reference : TS
ƒ ƒ Scaffold for all other Track Gauges and all other Height up to 7.5 m (to be specified)
ƒ ƒ ECR-12 : Double Scaffold with Floor : 6.50 x 2.6 m. (on 2 Tracks)
ƒ ƒ PER-1 Double Scaffold with Extensions on the 2 Platforms (Total Length of the Floor = 10 m)
▷ ▷ Scaffold : ECR-1/ ECR-12
▷ ▷ Lateral Extension : DL-1 (0.6 or 1 m.)
▷ ▷ Safety Rail Tong : TS (Photo 2)
Safety Rail Tong - Ref. TS
for Works with Lateral Extensions
Working in Metro Station
ECR-1 + (2 DL-1 )
1 2 3
▷ ▷ ECR-1 (on 1 Track) = 2.6 x 1.90 m.
▷ ▷ ECR-12 (on 2 Tracks) = 2.6 x 6.5 m.
ECR-1
OPTION
TRANSPORT ON TRACK
Tese Specifications are given for your information onlyand may be technically modified and improved.
