SEC-1
TRACK SECURITY SET
Rep. Désignations
Spec. No.
Reference Weight Kg
1
1
Horn
, length 350 mm
2/9
1038
0.26
2
1
Wooden Case
with
6 Security Detonators
.
Dimensions : 500 x 90 x 65 mm
9/9
C-1036
1.68
3
1
Signal Lamp 3 Lights
rechargeable
220 V
Dimensions : 26 x 12 x 17 cm
7/8
L2F
2.1
4
1
Red Flag
, Length 1 m. with
Conical metal Tip
7/9
DRPM
0.65
5
1
Red Flare 8 minutes
Ø 50 mm x length 540 mm
9/9
1037
1.14
6
1
Safety Movable Brake with Red Flag
Length of the Block : 42 cm
Total Length with the Flag : 91 cm
The Flag may be standing perpendiculary to the
Track.
41/3
11MA
3.2
7
1
Shunt-Cable of the Rails
,
Length 2 m. (electrically insulated), with 2
Tightening Rail-Clips. Maxi amperage : 270 A
12/9
CS-1
3
This Set of Security
SEC-1
is compulsory for all tracted Materials circulating on Track and for all Works on Track.
It comprises :
OPTION :
ROLLING KNAPSACK
for Transport of the
Track Security Set and hand Tools
Dimensions : 55 x 38 x 25 cm
Weight = 4 Kg
Ref.
SDR
