Hygiene, Safety Protection and Signalling

Tese Specifications are given for your information only

and may be technically modified and improved.

Made in

SHUNT-CABLE AND LINKING CABLES

SHUNT-BAR -

Ref.

BS-1

«SNCF» Model, with two Hardened-Steel Nibs

A Strong Spring on a Hard Pression on the two Nibs.

Aluminium Body, with Handle

Length closed = 1.48 m.

Length in Track 1.55 m.

(for Standard Gauge = 1 435 mm)

Weight = 3.2 Kg

OPTION

: Transport Wooden Case - ref.

CBS-1

SHUNT-CABLE -

Ref.

CS-1

Cable Length 2 m.

Electrically insulated

with 2 Clips on Rails

MAXI Amperage 270 A

Weight : 3 Kg

USE :

Shunt of two Rails during the Track Works, and of Signalling.

ADVANTAGES :

Total Security Materials.

12/9

in Track Position

In Closed Position

Part of Set of Track Security - ref.

SEC-1

LINKING CABLE -

Ref.

CCE

Length. 2 m / 270 A

for electrical continuity of rails with 2 bronze Clamp

Brakets screwed on flange of rail

SOCKET ON RAIL -

Ref.

PMR

Intensity 600 A

Clamping on Flange of rail.
