HAND TOOLS
Made in
13/3
USE : Check the position of the sleepers when laying or replacing sleepers
ADVANTAGES : Simple and tough.
TRACK LAYING SQUARES
FIXED METAL SQUARE
Track gauge
(m)
Dimensions
(cm)
Weight
(Kg)
References
1.44 162 x 115 7.3 390
1 and 1.06 120 x 100 5 390-M
1.52 170 x 115 7.5 390-R
1676 190 x 115 8.7 390-G
REINFORCEDWOODEN SQUARE
Track gauge
(m)
Dimensions
(cm)
Weight
(Kg)
References
1.44 162 x 112 3.1 391
1 and 1.06 120 x 100 2.7 391-M
1.52 170 x 112 3.3 391-R
1676 190 x 115 3.6 391-G
FOLDING METAL SQUARE Ref. PL (transport casing - Ref. ET1)
FOLDING PLASTIC SQUARE - Reference PVC
For track 1.44 m - Dimensions = 164 x 115 cm
Folded = 162 x 110 cm
Weight = 7 Kg
Transport casing Ref. ET2 = Ø 16 cm - Length 170 cm
OPTIONS
- Insulated metal square (for track gauge 1.44 mm) - Ref. 390-1
- Aluminiummetal square (Weight 4 Kg) - Ref. 390-A
