MEASUREMENTS AND CONTROL EQUIPMENTS
Made in
2/7
USE : Check the Torque of the Coachscrews, the Fishbolts and the Rail Bolts.
ADVANTAGES : Very Accurate and Reliable Equipment.
TORQUEWRENCH CONTROL
HALF-MOON GAUGE
To check the tightening Torque for the Standard Installation
Net Weight = 0.27 Kg
Reference : JC-1
ƒ ƒ Capacity : from 7 to 35 daNm
ƒ ƒ Total Length = 770 mm
ƒ ƒ Drive Ø 3/4’’
ƒ ƒ Net Weight = 2.2 Kg
ƒ ƒ Reference : CDY (supplied without socket)
ƒ ƒ Supplied with rigid Box
ƒ ƒ Total Weight 3 Kg
SOCKETS (Unit Weight 0.5 Kg) :
cSquare : 21 mm Ref. 136-A6
23 mm Ref. 136-A5
27 mm Ref. 137-C9
6 pans : 36 mm Ref. 137-C8
38 mm
40 mm
Ref. 137-C7
Ref. 137-C9
DYNAMOMETRICWRENCH
SET OF THICKNESS - WEDGES
Length of blades 90 mm
Width of blades 10 mm
Quantity of blades 19
Thickness of blades in 1/10 mm
Net Weight 0.6 Kg
Reference : JC-2
Options : Other Measuring Capacity until 150 da.Nm (on request)
