DEVICES FOR MEASURING RAILWEAR
USE : Checking and Measuring Wear of the Rails.
ADVANTAGES : Accurate Device.
SLIDE CALLIPER RULE - ref. 1019
ƒ ƒ AIl steel
ƒ ƒ Scaled from 0 to 180 mm
ƒ ƒ Total Length = 310 mm
ƒ ƒ Width of Jaws = 70 mm
ƒ ƒ Weight : ▷ ▷ Slide Calliper Rule = 0.75 Kg
▷ ▷ Wooden Case = 0.50 Kg
ASTRIDE CALLIPER - ref. 1020
ƒ ƒ It is laid on top of the rail to measure Vertical and Lateral Wear
ƒ ƒ Stainless Steel
ƒ ƒ Special Device for each Rail Section
ƒ ƒ Weight : 1.4 Kg
ƒ ƒ With Level Control of inclination of the Rail
(at 1/20e or at 1/40e )- Ref. 1022 - Weight : 1.3 Kg
CALLIPERS FOR MEASURING THEWEAR of the interior of rail - ref. 1021
ƒ ƒ Fixed under the Skid of the Rail
ƒ ƒ Weight 2 Kg
