USE :
Measure the rail temperature, with tables for rails joints.
Length 18, 24 and 36 m (for expansion devices : See Charts)
ADVANTAGES :
Simple and Accurate Devices.
RAIL THERMOMETERS
FLAT THERMOMETER «SNCF» Model
Aluminium Rectangular Body
Scaled from -20 to +60° C
Length = 145 mm
Width = 28 mm
Thickness = 12 mm
Weight = 200 gr.
Reference :
38
CIRCLE THERMOMETER
Body in brass Ø 10 mm with ring
Graduations : -20° to +65° C
Length = 154 mm
Weight = 40 gr.
Reference :
38-R
THERMOMETER INTO A PIECE OF RAIL,
with Handle and Cover Plate.
(This Device enables users to find out the Exact Temperature inside the rail)
Length of rail = 170 mm
Weight = 7 Kg
References :
(Supplied painted, to indicate the colour or no-painted)
OPTIONS
THERMOMETER with 2 sticked magnets (
to attach it to the rail) - Ref.
38-A
Wooden Case
- Dimensions : 16 x 4 x 3 cm - ref.
38-CO
Protective Leather Casing
- ref.
38-E
▷
▷
with Flat
Thermometer ref. 38
----- Ref.
39
▷
▷
with Circle
Thermometer ref. 38-R
-- Réf.
39-C
