MEASUREMENTS AND CONTROL EQUIPMENTS

Made in

12/7

USE :

Check the distance between Wagon wheels (setting), Inner sides of the axles.

ADVANTAGES :

Simple and accurate.

GAUGES SPACING OFWAGONWHEELS AND CALLIPER RAILWEAR

▷

For Standard Gauge 1350 to 1390 mm - Ref.

RW-N

▷

For Metric Gauge 900 to 970 mm -

RW-E

Body in Steel (paint : yellow) - «

SNCF» Model

End section in treated steel, interchangeable

With integrated graduated Indicator

Measurement capacity :

Direct Read Measurement Indicator -

Accuracy ± 0.1 mm.

Chrome Rotating Part

Net Weight = 3 Kg (Standard Gauge) / 2.3 Kg (Metric Gauge)

Delivered in Iroko varnished wood case, with fasterners and handle.

(The gauge measure is placed on a foam cushion in the box).

E.I. GAUGE (Measuring Tool for Spacing of Wheels internal and active Faces

CALLIPER FOR MEASURING THE RAIL-WEAR - Ref.

586

To indicate the rail-section
