HAND TOOLS
Tese Specifications are given for your information onlyand may be technically modified and improved.
Made in
MANUAL LIGHTWEIGHT PLATFORMTROLLEYS - NEW GENERATION
32/3
All our platform Trolleys are equipped with BRAKING DEVICES and the 4 wheels are electrically insulated.
They are designed with 2 side handles for manipulation by the Operating Agents.
Standard dimensions (for 1.44 m track) : 175 x 75 cm / (for Metric Gauge) : 132 x 75 cm
The Brake Lever can be positionned on the two sides and is dismountable.
REFERENCES Load
Capacity (Kg)
Parking
Brake on 2
Wheels
AUTOMATIC BRAKE
Weight
(Kg) on 2Wheels on 4Wheels
PL1T
PL2T
PL5S
500
1000
2000
x
x
x
48
52
63
«SNCF» AGREED
STANDARD LGV Ref. (*)
500
1000
500
1000
x
x
x
x
53
57
55
59
PL1S
PL2S
PL3S
PL4S
PL1S-LGV
PL2S-LGV
PL3S-LGV
PL4S-LGV
ƒ ƒ MOTORIZED PLATFORM - See Sheet No. 5/4
ƒ ƒ LARGE-WIDTH PLATFORMTROLLEY - Ref. GL
ƒ ƒ SIDE ROLLERS - Ref. GR
ƒ ƒ ODOMETER with Trolley - Tech. Spec. No. 6/7
Double Iightweight platform Ref. PL5S-GR
Trolley with automatic brakes and Lateral wheels
Load capacity : 2000 Kg
Dimensions = 200 x 175 cm
coupled with Odometer Braking with Linkage
OPTION
Manual Super-Lightweight PlatformTrolley - Ref. PL6S
Load Capacity : 500 Kg
Dimensions = 175 x 50 cm
Weight : 25 Kg
USE : Transport of all equipement and materials on the track over short distances.
Max load : 500 Kg to 2 tons.
ADVANTAGES : Guaranteed, lightweight (aluminium) and tough equipment that
offers total safety of use.
(*) LGV Models , New Generation are authorized
to circulate on High Speed Lines and on Standard
Tracks. Height of the Floor at the Running
Surface of the rail = 280 mm
