HAND TOOLS
Made in
USE : Re-railling of derailedWagons
ADVANTAGES : Tough Equipment, both durable and simple to use.
Excellent price / force ratio.
ƒ ƒ Steel Body and Carriage
ƒ ƒ Steel Screw and Head
ƒ ƒ Bronze, High-Resistance Nut for the Vertical Screw Arm Carriage Slide Nut.
ƒ ƒ Delivered complete with two Operating Ratchets.
ƒ ƒ Paint : yellow varnish
ƒ ƒ References : VM-71 to VM-77
Type 71 72 73 74 75 76 77
Lifting Capacity T 5 10 15 20 25 30 50
Ø Screw mm 49 59 69 74 83 89 100
Lifting Stroke mm 220 230 230 230 230 230 200
Mini Height mm 490 510 580 580 610 650 700
Horizontal Stroke mm 170 270 330 330 330 330 300
Unit Net Weight Kg 37 55 65 75 80 85 90
OPTIONS
ƒ ƒ RE-RAILING RAMPS - Ref. R-9 - See Tech. Spec. No. 36/3
ƒ ƒ HYDRAULIC JACKS (See Tech. Spec. 2/5)
MECHANICAL SCREW LIFTING JACKS
37/3
