HAND TOOLS
Tese Specifications are given for your information onlyand may be technically modified and improved.
Made in
6/3
CLAMPS OF FISHPLATES
USE : Fast Tightening of Fishplates on Track (or on Work-Sites).
Tightening of stopping Shoes.
ADVANTAGES : Allow the freely circulation of the Heavy Machines
on track (Ballast Cleaning Machine - Ref. 64N Model).
ƒ ƒ Body in forged steel
ƒ ƒ Tightening screw in hardened steel with 38 mm flat hex ends
ƒ ƒ Ø 22 mm Centring Pins
ƒ ƒ Tightening Screw Stroke : 100 mm
ƒ ƒ Net weight 8 Kg
ƒ ƒ Paint yellow varnish
Clamp of fishplates - Ref. 64N
(does not engage the track gauge)
ƒ ƒ Flat steel C-Wench
ƒ ƒ with 2 Ø 30 mm hex head socket screws
ƒ ƒ Ø 22 mm centring pins
ƒ ƒ Weight : 9 Kg
Clamp of fishplates in forged steel «SNCF» Model - Ref. 64
Clamp of fishplates small size - Ref. 64R
ƒ ƒ C35 CD-4 Steel
ƒ ƒ Tightening screw : 160 mm
ƒ ƒ Net weight 8.5 Kg
OPTIONS
ƒ ƒ Clamp for 230 mm Tyre-Rail- Reference : C-230
ƒ ƒ Clamp for 250 mm Tyre-Rail with 2 pcs, quick tightening- Reference : C-250
Spare Parts of the Clamp of fishplates Ref. 64
ƒ ƒ Ø 22 mm centring pins - Ref. C-22
ƒ ƒ Short Tightening Screw - Ref. V-33
ƒ ƒ Long Tightening Screw - Ref. V-34
ƒ ƒ Spare Parts Kit = C-22 + V-33 + V-34 = Ref. K-64
