GAUGES AND CALLIPERS
USE : Various Inspections and Measurements (Controls)
ADVANTAGES : Simple and Tough.
GAUGE for inspecting the tightness of clips
« RN » (french clips) - Angled Model
ƒ ƒ Scaled 0.3 to 5 mm
ƒ ƒ Length : 150 mm
ƒ ƒ Weight = 60 gr.
ƒ ƒ Reference : 579-1
CALLIPERS for inspecting the
balf-open
position of the switches
ƒ ƒ 5/6/8 mm wedges
ƒ ƒ Length 140 mm
ƒ ƒ Aperture = 20.5mm
ƒ ƒ Weight = 0.17Kg
ƒ ƒ Reference : 585
GAUGE 3 points in for NABLA Clips
For NewTrack :
CAM INDICATOR (For Nabla Clips)
Scaled : 0 to 5 mm
ƒ ƒ Weight = 0.260 Kg
ƒ ƒ Reférence : CNA
Portable POUGET TEST-NABLA (French clips)
Use to measure the curvature of the Nabla clip on
the track after tightening.
ƒ ƒ Measurement stroke = 10 mm
ƒ ƒ Measurement accuracy = 1/10e mm
ƒ ƒ Delivered with woodencase = 30x30x10 cm
ƒ ƒ Weight of the device in the case = 4 Kg
ƒ ƒ Reference : PTN
Direct Reading
Direct Reading
Standard Tightening 1.5 mm
Weight : 0.3 Kg
Ref. G3P
For Maintenance and Liberation : (controls 1 and 2 mm)
Weight : 63 gr.
Ref. G3P-A
Gauge for Inspecting the Play of the Fishplate
ƒ ƒ Scaled 1 to 20 mm
ƒ ƒ Cadmium plated for protection
ƒ ƒ Length = 230 mm
ƒ ƒ Weight = 0.25 Kg
ƒ ƒ Reference : 580
MULTIPLE CONTROLLER
for NABLA - CLIPS - Sheet No-5/7
Double Tightening 1 and 1.5 mm
Weight : 0.3 Kg
Ref. G3P-2
