GAUGE RETAINING BAR / DEVICE TOWIDEN OR NARROW THE GAUGE
USE : Gauging the Tracks.
SAFETY : Compulsory for tracks with broken Coachscrews or Bolts
ADVANTAGES : Doesn’t engage the Rail Gauge.
GAUGE RETAINING BAR
ƒ ƒ Body made of high-resistance steel piping with hooks for the rail flange.
ƒ ƒ Stroke = 240 mm
ƒ ƒ Operates by tightening using a 38 mm hex head nut on the fiat.
ƒ ƒ Length = 1.88 m. (for standard gauge 1435 mm)
ƒ ƒ Weight = 11 Kg
ƒ ƒ Paint : yellow vanish
The Bar is positioned UNDER the track
ƒ ƒ Electrically insulated Device - Reference : 111
ƒ ƒ No-electrically insulated device - Reference : 111-N (Other Gauges on request)
OPTIONS
ƒ ƒ Bar for other Gauges, (on request)
The Bar is positioned ABOVE the track.
ƒ ƒ No-Electrically insulated - Ref. 112-N
Weight : 11 Kg
ƒ ƒ Electrically insulated - Ref. 112
Weight : 11 Kg
ƒ ƒ Electrically insulated - Reference : R-111
ƒ ƒ No-electrically insulated - Reference : R-111-N
For Switches and Crossings : Adjustable Extension Bar (in 3positions) (Stroke 200 mm)
