TRACK LINING AND LEVELLINGWORKS
Tese Specifications are given for your information onlyand may be technically modified and improved.
8, allée du Val du Moulin - B.P. 69 - 93240 STAINS - FRANCE
Tél. : 33. (0) 1. 48 26 62 12 - Fax : 33. (0) 1.48.22.37.15
E-mail : - Web :
Made in
OPTIONS
ƒ ƒ RAIL LIFTING JACK Ref.106 with Shifting Skid (supplied with Removable Shaft) - Ref. 106-P
ƒ ƒ SHIFTING SKID - Ref. P
3/5
MECHANICAL RAIL-LIFTING JACKS
USE : Track Lifting (Repairing Works, Laying New Track, Tamping, Maintenance, etc. )
Laying Switch and Crossings.
ADVANTAGES : Very Tough Equipments with Guarantee.
Complie with European Safety Standards.
JACKS BY RISING RACK
with Safety Crank Handle
103 5 400 42
102-B 10 825 71
SIMPLEX JACKS BY RISING RACK
with Pawl
107 5 240 15.5
108 10 305 30
109 15 290 37
110 20 455 47
JACKS BY RISING BEAM
with Safety Crank Handle
105 3 350 25
101 5 360 34
101-C 10 320 45
101-D 16 320 72
101-E 20 300 97
TAMPING JACKSWITH OPERATING LEVER
(does not engage the Rail Gauge)
Complete with Crank Handle
Length 1.45 m (Weight Lever = 7 Kg)
Ref. Force (T)
Lifting
Stroke
(mm)
Weight
(Kg)
Shoe
106 5 200 25 Steel
106-L 5 200 20 Alu
References Force(T)
Lifting
Stroke
(mm)
Weight
(Kg) References Force(T)
Lifting
Stroke
(mm)
Weight
(Kg)
Shifting Skid - Ref. P
(for Rail Lifting Jack - Ref.106 and 106-L )
