TRACK LINING AND LEVELLINGWORKS
Tese Specifications are given for your information onlyand may be technically modified and improved.
8, allée du Val du Moulin - B.P. 69 - 93240 STAINS - FRANCE
Tél. : 33. (0) 1. 48 26 62 12 - Fax : 33. (0) 1.48.22.37.15
E-mail : - Web :
Made in
4/5
LEVELLING TELESCOPES
USE : Track Levelling Works, (Renovation, Maintenance and Repair Work)
ADVANTAGES : Very Accurate and Reliable.
Reference Magnification Read at ... m
WEIGHT (Kg)
Telescope Levelling
Sight
LM24X
LM50X
24 Times
50 Times
40
80
11
13
3
3
Telescope and Levelling Rod on Stand (Height above the Rail = 110 cm)
(The telescope includes a Graduated Levelling Sight with Bubble Level)
LowTelescope (Height above the Rail = 18 cm)
(The Telescope includes a Graduated Levelling Sight (5 Graduations) with Bubble Level)
Reference Magnification Read at ... m
WEIGHT (Kg)
Telescope Levelling
Sight
220
235
24 Times
50 Times
40
80
3
3
2
2.2
OPTIONS
ƒ ƒ For Low Telescope : Track Lining Rule mounted to the back of the Levelling Sight - Ref. 225
ƒ ƒ Transport cases (telescope + levelling sight) : ▷ ▷ for Telescope on Stand (wooden) = 17 Kg - Ref. 222
▷ ▷ For Low Telescope (metal) = 5.3 Kg - Ref . 221
