Made in

POUGET «

PM-12-BEL

» TRACK INSPECTION VEHICLE

11/4

The Track Inspection Vehicle

PM-12-BEL

is motor-driven. Manufacturing in ALL ALUMINIUM, and

derailable very easily by 4 men.

TECHNICAL CHARACTERISTICS

DIMENSIONS :

For Standard Gauge 1435 mm : 192 x 147 cm

Metric Gauge 1000 mm : 192 x 104 cm

Height 150 cm + dismantled at 2.05 m

SPEED RUNNING

: 0 to 6 Km/H

WEIGHTS :

Vehicle = 150 Kg / Generating Set = 150 Kg

LOADING CAPACITY

: 1000 Kg

SOUND LEVEL

: Electric Motor = 54 dB(A) / Generating Set = 62 dB(A)

Equipped with

3 Seats

for the Agents, and

1 Seat

for the Driving Operator.

MOTORIZATION :

1 Electric Motor : 3 kW - Triphase 380 V - 50 hZ

1 Generating Set - 5 kW - Triphase 380 V - 50 Hz

RUNNING DEVICE / BRAKES

2 AluminiumWheels, electrically insulated Ø 250 mm

2 AluminiumWheels, with Rubber Tire electrically insulated Ø 280 mm

2 Brakes by foots on the Wheels-Rubber Tire.

1 «Dead-Man» foot brake, actionned by the Operator.

1 Reversing Gear (Front / Rear)

1 Control Pulpit, with reversing-gear device, Stop, and PROXYDRIVE Speed Converter.

SAFETY DEVICES

Demountable Lateral Guardrails (Height 1 m.)

4 Signal Lamps (Red/White) with led bulb.

2 Led Projectors 100 W / 230 W for the night works.
