MACHINES FOR TRACK WORK
Made in
10/1
PORTABLE IMPACT WRENCHES
PORTABLE IMPACTWRENCH S1-P
- With reverser of direction
- 2-stroke Petrol Engine - 1,7 kW
- Max. Torque = 100 da.Nm (Adjustable at 0 to 100 da.Nm)
- Dimensions :
Standard Drive Square : 25.4 mm - Option : 23 mm
- Net Weight : 19 Kg
ƒ ƒ Length : 760 mm
ƒ ƒ Heigth : 350 mm
ƒ ƒ Width : 390 mm
OPTIONS
ƒ ƒ Low-Vibration Device - Weight = 1 Kg
ƒ ƒ Reinforced Socket for Impact Wrench treated in Special Nickel Chrome Vanadium Steel - Tech Spec. NO. 3-2/2
ƒ ƒ Other ACCESSORIES - Tech. Spec. 8-1/2 and 8-2/2
OPTIONS
PORTABLE ELECTRIC IMPACTWRENCHES 220 V / 50 Hz (It is forbidden to use them in the rain )
ƒ ƒ Max. Torque 60/dN.m - Weight 8 Kg - Ref. TBE-20
ƒ ƒ Max. Torque 100/dN.m - Weight 10 Kg - Ref. TBE-30
PORTABLE IMPACTWRENCH S4-P
This Portable Machine allows to work on track through the use of S1P Impact Wrench
and can be easily taken from the Track by one Operating Agent.
WEIGHT OF THE COMPLETE MACHINE : 35 Kg
TECHNICAL CHARACTERISTICS
• S1P Impact Wrench, with a 2-stroke Petrol Engine
Power 1.7 kW - Max Torque : 100 da.Nm, Adjustable.
with reverser direction of the rotation - Square Drive 25.4 mm
(Sockets - available in all dimensions) - See the Tech. Spec. No. 3-2/2
• All aluminiumTrolley Support, with Pivoting Reinforced Pneumatic Shock Absorber.
Dismantable Aluminium Bar-Trolley with insulated Nylon Roller - Weight : 14 Kg
POUGET ‘s I n n o v a t i o n
OPTION : PORTABLE ON BATTERY 18 V Coachscrewing Machine with Trolley S5PT (Wrench Sheet 11/1)
