RAIL WELDING EQUIPMENTS
Made in
2/6
WELDING RULES AND SQUARE
USE : Check the Rail Squaring before welding.
ADVANTAGES : Gauge to allow the square to fit in the gap between the 2
rails to be welded..
WELDER SQUARE ES-1
(For aluminothermic weldings)
To check the Interval between rails
Hard Steel (Inox)
Length : on the rail head 120 mm
into the interval 180 mm
Width : 17 mm
Weight : 0.5 Kg
BEVELLED RULES
Body in Bevelled Stainless Steel with Handle.
Accuracy = 1/10th mm
Ref. Length
(m)
Weight
(Kg)
RC-5 0.5 1.5
RC-10 1 3
RC-15 1.5 4.5
RP-10 FLAT RULES (Steel)
For Rail Adjustment before welding
Rectangular Section : 50 x 12 mm - Length 1 m
Weight = 4.7 Kg
with chromatic protection.
OPTIONS
ƒ ƒ Protective Sleeves for RC-10 Rule - Ref. FPR-10
ƒ ƒ Protective Sleeves for RC-15 Bevelled Rule - Ref. FPR-15
RP-10
RC-5
17
WELDER SHORT RULER WSR-20
To control the space before welding
Width 18 mm / Thickness 0.5 mm
Stainless steel
2 scales : 0-20 / 0-200 mm
