www.pougetrail.comMACHINES FOR TRACK WORK
Tese Specifications are given for your information only
and may be technically modified and improved.
Made in
21/1
The
«POUGET» VT- 3 Vibrating Tamping Set
is equipped with :
1 Generating Set
(Petrol or diesel) Triphase 220/380 V - 50 Hz
FUEL
MOTOR
POWER (KVA)
WEIGHT
(Kg)
Petrol
HONDA
LOMBARDINI
6
7
100
106
Diesel
HATZ
LOMBARDINI
6
112
STANDARDVT-3 PORTABLE VIBRATING TAMPING SET
4 «POUGET» PORTABLE VIBRATING TAMPERS
at individual drive, with an automatic Safety Switch
10 m. insulated protective cable. MULTIPLE VIBRATING DIRECTIONS
Unit Power : 0.77 kW - Vibrating Frequency : 50 Hz - Overcurrent discontactor 30 mA.
Vibrating Strength of Tamping-Blade : 660 Kg
Unit Weight of each Tamper : 32 Kg
1 ELECTRICAL BOX
with Cable of 50 m., Emergency Stop Button, Security Connections,
and General Circuit Braker -
Weight : 32 Kg
Noise Level
for the Operating Agent : 90 dB(A)
Vibrating Level
on the Operating Agents Handles : 5 m/S²
OPTIONS
: Vibrating Damper at the Operating Agent Handles Device - Ref.
AV-2
Wheel-Barrow with a single Wheel to transport the Tie Tamper - Ref.
EMB
Platform Trolley to transport the VT-3 Tamping Set on Track - Ref.
PL-VT3
IMPORTANT : The Tip of Tamping-Blades is strenthened with Hard Metal (Hardness HRC 63/68)
All the
Generating Sets
are mounted on 2 Rubber
Inflatable Wheels
Various electric Tools as Portable Grinding Machines, Drilling Machines, Screwing Tools, etc.
can be connected on the Vibrating Tamping Set.
