MACHINES FOR TRACK WORK
Made in
22/1
USE :
Working of deep grooves on rail (Metro with Tyres).
Width of the rail : 230 à 280 mm (to specify)
ADVANTAGES :
This Machine allows to make several different pitches: 8/10/12/24 mm
«R2P»
GROOVING MACHINE FOR TYRE-RAIL METRO
CHARACTERISTICS:
MOTORIZATION :
Electrical (Triphase 220/380 V)
HONDA 4-stroke Petrol Engine
Diesel HATZ
R2P-E
R2P-T
R2P-D
FEED :
Automatic feeding by Drive-Rollers on the sides of Tyre-rail
TOOL :
The Tool with tungsten carbide makes grooves of a radius
150 mm - Depth of passage = 2 mm
EFFICIENCY :
25-30 m / Hour (Pitch 10 mm)
LIGHTING :
A Damp-proof orientable Projector lights the Working Zone
Dimensions
:
130 x 46 x 81 cm
Net Weight :
320 Kg (for Width of Rail 230 mm.)
Profil View
Front View
Grooving Tyre-Rail
Cable Reel 50m
Ref. RO2P-E
Nota
: The Cable Reel on Rollers allows to supply electrically the
R2P-E
Grooving
Machine on 50 m. Length- Ref.
RO2P-E
.
Spare PARTS
: Carbide-Tool with very Hight Resistance to repeated Impacts.
