MACHINES FOR TRACK WORK
Tese Specifications are given for your information onlyand may be technically modified and improved.
Made in
23/1
USE : Loading and Unloading of rails on Wagons (in Track, or in Site-Work)
RAIL LOADER ONWAGON (motorized or manual)
MANUAL RAIL LOADER PM-1
ƒ ƒ 1 Stand Support on the top of the Wagon
ƒ ƒ 1 Adjustable Boom Arm, tilted with Folding End Section
ƒ ƒ 1 Chain Block with Crank Handle Lifting Cable Rail Tong in forged Steel.
ƒ ƒ 1 End Truck on Boom Arm
ƒ ƒ Length of Boom Arm = 3.50 m
ƒ ƒ Lifting Capacity = 1 ton
ƒ ƒ Weights : Support Stand = 77 Kg / Boom Arm with Chain Block and Truck = 115 Kg
ƒ ƒ Paint Yellow Varnish
The Stand Support may be attached with the Wagon : - either by Bolt Clamping
- or by Chain and Tensioner (To specify)
MOTORIZED RAIL LOADER PMO (Petrol or Diesel Engine)
ƒ ƒ Power 6 HP
ƒ ƒ Lifting Capacity : 1000 Kg
ƒ ƒ Reverser Direction and Safety Brakes
ƒ ƒ Support Stand : 77 Kg - Motorized Boom Arm : 160 Kg
The Width of the Wagon Platform will be specify.
