PORTABLE GRINDERS FOR RAIL CORRUGATION
This Machine allows the Grinding of the Rail Corrugation (The Guiding Database being the up-running
Surface of the Waves Rails).
It is equipped with Different Ø cup Grinding Wheels, as the Type of rail to grind.
TECHNICAL CHARACTERISTICS
ENGINE
: HONDA 4-stroke Petrol Engine - GXV-160 Model
Displacement 163 cm³ - 4.3 HP (3.2 kW).
CUP GRINDINGWHEELS
: 4 Grinding Wheels Diameters can be fitted on this Machine.
MachinesModels Ø
Grinding Wheel (mm)
N-16-A
N-16-B
N-16-C
N-16-D
52 (for Tramway Track)
72
115
150
GUIDING OF ON RAILS
: 2 Ramps equipped with 12 rollers each, mounted on Water-Tight
Ball Bearings, circulating on the Running Surface of rail to grind.
4-Side Guide Rollers on the Internal Sides of Rails.
GRINDING ADJUSTMENT
: Inclination Adjustment of Grinding Wheel on the Transversal Bar-Guiding.
Depth Adjustment of the Grinding by a Driving and Screw Control on one
of the both Guiding Ramps.
Net Weight
: 58 Kg
